LSQ-S2 Close Type Hydraulic Quick Coupling with Double Shut-Off and Hardened Durability for 2000-5000 Psi Applications

Categories	Hydraulic Quick Connect Couplings
MOQ:	1
Price:	1.4
Model NO.:	LSQ-S2 (ISO B STEEL)
Working Pressures:	2000-5000 Psi
Interchangeability:	ISO 7241-1 Series B, Poppet Valve
Valve Type:	Poppet valves
Locking Mechanism:	Ball-locking
Material:	Steel
Socket Material:	Solid bar stock
Compatible Series:	PARKER 60, FASTER HNV, AEROQUIP FD45, HANSEN HK
Length (LS):	48-103 mm
Diameter (D):	24-63.5 mm
Hex Size (HEX1):	17-41 mm
Thread Size (T):	G1/8 NPT1/8 to G1 NPT1
Length (LP):	29-63 mm
Bore Diameter (d):	10.8-37.8 mm
Hex Size (HEX2):	14-41 mm

Contact Now

Add to Cart

Company Info.

Zhejiang Songqiao Pneumatic And Hydraulic CO., LTD.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

LSQ-S2 Close Type Hydraulic Quick Coupling with Double Shut-Off and Hardened Durability for 2000-5000 Psi Applications

LSQ-S2 Close Type Hydraulic Quick Coupling(Steel)
Applications: LSQ-S2 couplings, are used across the spectrum of hydraulic applications. These Double Shut-Off couplings can be found anywhere that fluid transfer lines need to be connected and disconnected for operation or maintenance of equipment, and a loss of fluid is undesirable. LSQ-S2 are used in construction quipment, Forestry equipment, agricultural machinery, oil tools, Oil equipment, steel mill machinery, and other demanding hydraulic applications.
LSQ-S2 Series couplings feature:
1. Poppet valves available to prevent uncoupled leakage.
2. Poppet valves open automatically when coupled, within rated working pressure, to keep the flow expeditely.
3. Critical parts are hardened for durability.
4. Dependable ball-locking mechanism holds the mating halves together.
5. Socket and plug are precision machined from solid bar stock.
6. LSQ-S2 series conforms to the standard of ISO 7241-B.
7. Compatible with PARKER 60 Series, FASTER HNV Series, AEROQUIP FD45 Series and HANSEN HK Series.

LSQ-S2-SF detail information see TABLE 1

ISO	PARTNO.	LS	¢D	HEX1	A	T
5	LSQ-S2-01SF	48	24	17	9.5	G1/8 NPT1/8
6.3	LSQ-S2-02SF	58	28.5	19	13	G1/4 NPT1/4
10	LSQ-S2-03SF	65	35	24	13	G3/8 NPT3/8
12.5	LSQ-S2-04SF	74	44.5	28.5	20.5	G1/2 NPT1/2
20	LSQ-S2-06SF	92	54	36	22	G3/4 NPT3/4
25	LSQ-S2-08SF	103	63.5	41	23	G1 NPT1

ISO	PARTNO.	LP	d	C	HEX2	A	T
5	LSQ-S2-01PF	29	10.8	19	14	9.5	G1/8 NPT1/8
6.3	LSQ-S2-02PF	36	14.2	22.8	19	13	G1/4 NPT1/4
10	LSQ-S2-03PF	40	19	25	24	13	G3/8 NPT3/8
12.5	LSQ-S2-04PF	46.5	23.5	28	28.5	20.5	G1/2 NPT1/2
20	LSQ-S2-06PF	56	31.5	36	36	22	G3/4 NPT3/4
25	LSQ-S2-08PF	63	37.8	45	41	23	G1" NPT1

ISO	PARTNO.	L	¢D	HEX1	HEX2	T
5	LSQ-S2-01	58.5	24	17	14	G1/8 NPT1/8
6.3	LSQ-S2-02	72	28.5	19	19	G1/4 NPT1/4
10	LSQ-S2-03	80.5	35	24	24	G3/8 NPT3/8
12.5	LSQ-S2-04	93.5	44.5	28.5	28.5	G1/2 NPT1/2
20	LSQ-S2-06	112.5	54	36	36	G3/4 NPT3/4
25	LSQ-S2-08	126.5	63.5	41	41	G1 NPT1
