| Categories | Spot Projection Welding Machine |
|---|---|
| Brand Name: | Xinweihan |
| Place of Origin: | Sichuan, China |
| Certification: | CE |
| MOQ: | 1 set |
| Price: | $35,000-40,000 / set |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Supply Ability: | 10 sets per month |
| Delivery Time: | 25-45 working days |
| Packaging Details: | wooden box |
| Product Name: | Automatic Tank Welding Machine with Multi-Process Capability |
| max. welding thickness: | 6+6 |
| rated capacity: | 100/160/200/250KVA |
| voltage: | 380V/220V |
| rated duty cycle: | 50% |
| usage: | Spot Welding |
| After Warranty Service: | Video technical support, Online support and Spare parts |
| After-sales Service Provided: | Free spare parts, Field installation, commissioning and training |
| Machinery Test Report: | Provided |
| Warranty of core components: | 1 Year |
| Company Info. |
| Chengdu Xinwei Welding Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
This Stationary Spot Welding Machine is a micro-computer controlled system designed for automated projection and spot welding applications, with a common use in fabricating components like automotive fuel tanks. Operating on a 380V/50Hz three-phase AC power supply, it utilizes three-phase rectifier and inverter technology along with a feedback control system to manage the welding heat cycle. This includes control over pre-press, weld, hold, and off times to meet specific welding requirements. The machine offers multi-process capability for materials such as low-carbon steel, stainless steel, and non-ferrous metals.
| Items Models | DN(B)-100 | DN(B)-160 | DN(B)-200 | DN(B)-250 |
|---|---|---|---|---|
| Rated power (KVA) | 100 | 160 | 200 | 250 |
| Power input(V) | 3φAC 380V | 3φAC 380V | 3φAC 380V | 3φAC 380V |
| Max. short circuit current (KA) | 30 | 35 | 40 | 45 |
| Duty cycle(%) | 50 | 50 | 50 | 50 |
| Max. force(N) | 6000 | 6000 | 10000 | 15000 |
| Electrode length( MM) | 450 | 450 | 450 | 500 |
| Working stroke( MM) | 80 | 80 | 80 | 80 |
| Cooling consumption(L/min) | 20 | 20 | 20 | 20 |
| Max. welding capacity(MM) | 3.0+3.0 | 4.0+4.0 | 5.0+5.0 | 6.0+6.0 |
A. Controlled & Versatile Welding Process
Programmable Welding Cycles: Micro-computer control allows for precise management of the welding sequence, including pre-press, weld, hold, and off times, aiming to accommodate different material and thickness requirements.
Multi-Material Application: The system is designed to weld a range of materials including low-carbon steel, stainless steel, coated steel, and non-ferrous metals in forms such as wire, sheet, and pipe.
B. Robust Power & Stable Construction
Dedicated Resistance Welding Transformer: Equipped with a specialized transformer featuring forced internal water-cooling and high-grade silicon steel, designed for strong power output and a high-duty cycle in industrial environments.
Stable Pressure Application: The machine structure incorporates upper and lower electrodes with an auxiliary stroke pressure mode, intended to provide stable application of force during welding.
C. Adaptive & User-Friendly Operation
Multiple Program Storage: The micro-computer controller can store up to 16 sets of welding parameters, facilitating quick changeover for different production jobs or material types.
Broad Industry Application: Engineered for use in various industries such as automotive, appliances, and hardware for projection welding processes on components like nuts, studs, and brackets.
|
