Solid Liquid Separator Machine - Disc Centrifuge
Huading Separator's disc centrifuges are engineered for
liquid-based applications, utilizing centrifugal force to separate
solids from liquids and liquid mixtures simultaneously. These
high-performance separators are essential across multiple
industries including chemical, pharmaceutical, food processing, and
biofuels.
Key Features
- All material-contact parts constructed from stainless steel
- Continuous automatic operation reduces labor costs
- Easy installation and maintenance
- High bowl rotation speed with VFD-adjustable G-force
- PLC control system with LED touch screen operation
- Automatic vibration detection and alarm system
- High-speed operation with stability and low noise
- Stable outlet pressure with large regulating sphere
Working Principle
The disc stack centrifuge separates solids and liquid phases in a
continuous process using extreme centrifugal forces. Denser solids
are forced outward against the rotating bowl wall while less dense
liquids form concentric inner layers. The interface position
between phases can be adjusted for maximum separation efficiency.
The disc stack design provides additional surface settling area,
dramatically accelerating the separation process. The specific
configuration and design of these plates enable continuous
separation of various solids from one or two liquids. Solids can be
removed continuously, intermittently, or manually depending on
application requirements.
Industry Applications
Vegetable Oil Refining
Soybean oil, sunflower seed oil, cottonseed oil, peanut oil, corn
germ oil, rice bran oil, sesame oil, linseed oil, coconut oil, palm
oil
Beverage Clarification
Fruit juices (tomato, apple, lemon, grape), vegetable juices
(celery, cucumber, garlic), beer, wine, coffee, tea
Animal Oil and Fats
Fish oil, kitchen waste oil, hogwash oil processing
Biodiesel Production
Separation of , glycerin, catalyst, methanol; washing of ;
extraction of fatty acid
Dairy Industry
Dairy clarification and skimming processes
Fermentation Industry
Algae processing (spirulina, chlorella, seaweed), yeast separation
(beer yeast, baker's yeast), molasses, syrup
Plant Extraction
Tea, rutin, loquat, honeysuckle, and other botanical extracts
Bio-Pharmaceutical
Microbial concentration, fermentation broth clarification, medical
protein purification, vaccine production, enzyme separation
Mineral Oil Processing
Fuel oil, lubricant treatment, drilling slurry processing, crude
oil water removal, waste oil treatment
Chemical Industry
Boiler ash, phosphoric acid, lye, fuel and paint, industrial salt
processing
Company Profile
With over 50 years of experience in centrifugal separation
technology, Huading Separator leads the industry in mechanical
separating solutions. Our disc stack centrifuges serve diverse
sectors including beverage, dairy, oil processing, chemicals, ,
biotechnology, starch technology, marine engineering, energy, and
oil fields.
Certifications & Quality Standards
