| Categories | Jinan Diesel Engine Parts |
|---|---|
| Model NO.: | PZ12V190B |
| Number of Strokes: | Four-Stroke |
| Cylinder Arrangement Form: | V |
| Number of Cylinders: | 12-Cylinder |
| Type: | Combustion Engine |
| Transport Package: | Wooden Cases |
| Specification: | 1000 |
| Trademark: | jichai |
| Origin: | China |
| HS Code: | 8409999000 |
| Supply Ability: | 50000pecises/Year |
| Ignition Mode: | Ignition |
| Speed: | High Speed |
| Cooling Cylinder: | Water-Cooled |
| Intake Pressure Impulse: | Naturally Aspirated |
| Piston Movement: | Reciprocating |
| Fuel: | Diesel |
| Customization: | Available | Customized Request |
| Place of Origin: | china |
| Certification: | ISO9001 |
| MOQ: | 1 |
| Price: | 10-1000 |
| Packaging Details: | Wooden box and carton packaging |
| Delivery Time: | 15 days |
| Payment Terms: | TT,western |
| Company Info. |
| Jinan Guohua Green Power Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
   | Model Z12V190B diesel engines | |||||||
| Model | Rated Power(KW/hp) | Rated Speed(r/min) | Specific fuel consumption(g/kw.h) | Specific oil consumption(g/kw.h) | Overall Dimension L*B*H(mm) | Net weigh(KG) | |
| Z12V190B | 882/1500 | 794/1500 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| PZ12V190B | 882/1500 | 794/1500 | ≤209.4 | ≤1.6 | 4301*1980*2678 | 7500 | |
| Z12V190B-3 | 820/1300 | 738/1300 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| PZ12V190B-3 | 820/1300 | 738/1300 | ≤209.4 | ≤1.6 | 4301*1980*2678 | 7500 | |
| Z12V190B-1 | 735/1200 | 662/1200 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| PZ12V190B-1 | 735/1200 | 662/1200 | ≤209.4 | ≤1.6 | 4301*1980*2678 | 7500 | |
| Z12V190B-2 | 588/1000 | 529/1000 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| PZ12V190B-2 | 588/1000 | 529/1000 | ≤209.4 | ≤1.6 | 4301*1980*2678 | 7500 | |
| Z8V190 | 588/1500 | 529/1500 | ≤213.5 | ≤2.7 | 2112*1560*2080 | 4300 | |
| PZ8V190 | 588/1500 | 529/1500 | ≤213.5 | ≤2.7 | 3950*1980*2678 | 6750 | |
| Z8V190-1 | 471/1200 | 425/1200 | ≤213.5 | ≤2.7 | 2112*1560*2080 | 4300 | |
| PZ8V190-1 | 471/1200 | 425/1200 | ≤213.5 | ≤2.7 | 3950*1980*2678 | 6750 | |
| Z8V190-2 | 390/1000 | 350/1000 | ≤213.5 | ≤2.7 | 2112*1560*2080 | 4300 | |
| PZ8V190-2 | 390/1000 | 350/1000 | ≤213.5 | ≤2.7 | 3950*1980*2678 | 6750 | |
| Main technical data | |||||||
| No. and arrangement of cylinders:12,60.Vee | |||||||
| Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection | |||||||
| Bore:190mm | |||||||
| Stroke:210mm | |||||||
| Total displacement:71.45L | |||||||
| Compression ration:14:1 | |||||||
| Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) | |||||||
| Starting method:Air motor or electric motor | |||||||
| Lubricating method:Pressure and splash lubrication | |||||||
| series 2000 diesel engines | |||||||
| Model | Rated Power(KW/hp) | Rated Speed(r/min) | Specific fuel consumption(g/kw.h) | Specific oil consumption(g/kw.h) | Overall Dimension L*B*H(mm) | Net weigh(KG) | |
| BG12V190ZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 3160*1770*2400 | 5300 | |
| BG12V190PZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 4374*1740*2400 | 8100 | |
| BG12V190ZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 3160*1770*2400 | 5300 | |
| BG12V190PZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 4374*1740*2400 | 8100 | |
| G12V190ZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| G12V190PZL | 900/1500 | 800/1500 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
| G12V190ZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| G12V190PZL-3 | 810/1300 | 730/1300 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
| G12V190ZL-1 | 740/1200 | 660/1200 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| G12V190PZL-1 | 740/1200 | 660/1200 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
| G12V190ZL-2 | 600/1000 | 540/1000 | ≤209.4 | ≤1.6 | 2692*1560*2070 | 5300 | |
| G12V190PZL-2 | 600/1000 | 540/1000 | ≤209.4 | ≤1.6 | 3860*2040*2678 | 8100 | |
| G8V190ZL | 600/1500 | 540/1500 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
| G8V190PZL | 600/1500 | 540/1500 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
| G8V190ZL-3 | 510/1300 | 460/1300 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
| G8V190PZL-3 | 510/1300 | 460/1300 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
| G8V190ZL-1 | 470/1200 | 425/1200 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
| G8V190PZL-1 | 470/1200 | 425/1200 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
| G8V190ZL-2 | 390/1000 | 350/1000 | ≤213.5 | ≤2.7 | 1802*1560*2070 | 4300 | |
| G8V190PZL-2 | 390/1000 | 350/1000 | ≤213.5 | ≤2.7 | 3280*2040*2678 | 6750 | |
| Main technical data | |||||||
| No. and arrangement of cylinders:12,60.Vee | |||||||
| Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection | |||||||
| Bore:190mm | |||||||
| Stroke:210mm | |||||||
| Total displacement:71.45(47.6)L | |||||||
| Compression ration:14:1 | |||||||
| Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) | |||||||
| Starting method:Air motor or electric motor | |||||||
| Lubricating method:Pressure and splash lubrication | |||||||

                             |
